TBC-410M Miniature Circuit Breaker (MCB) 4P 10A 6kA

Name: TBC-410M Miniature Circuit Breaker (MCB) 4P 10A 6kA
Brand: TBC
SKU: TBC-410M

TBC-410M

The TBC-410M is a professional-grade 4-pole miniature circuit breaker engineered to deliver dependable overload and short-circuit protection in low-voltage electrical distribution networks. Featuring thermal-magnetic trip technology with Type C characteristics, this MCB is ideal for residential, commercial, and light industrial applications where reliable circuit protection is essential.

Key Features

4-pole configuration for comprehensive three-phase and neutral protection
Type C tripping curve optimized for inductive loads and motor circuits
6kA breaking capacity suitable for most distribution applications
Thermal-magnetic trip technology for accurate overload and short-circuit detection
Fast tripping time under 0.1 seconds for enhanced safety
DIN rail mounting (35mm) for quick and easy installation
High mechanical durability rated for 20,000 operating cycles
Wide operating temperature range from -35°C to +70°C
Compact design: 72mm width for space-efficient panel layout
IEC 60898-1 compliant with CE, CB, and TÜV certifications
IP20 degree of protection for standard indoor environments
Toggle control for simple manual operation

Request Quote

The TBC-410M miniature circuit breaker represents a robust solution for protecting electrical circuits against overload and short-circuit conditions in demanding environments. With its 4-pole design, this MCB provides simultaneous protection across all phases and the neutral conductor, making it particularly suitable for three-phase installations.

Built with thermal-magnetic trip technology, the TBC-410M combines a bimetallic element for overload protection with an electromagnetic release for instantaneous short-circuit protection. The Type C tripping characteristic makes it ideal for circuits with moderate inrush currents, such as lighting circuits, small motors, and general power distribution.

Designed for professional installation, the breaker mounts securely on standard 35mm DIN rails and features a compact footprint that maximizes panel space utilization. Its robust construction ensures reliable performance across a wide temperature range, while multiple international certifications guarantee compliance with global electrical safety standards.

Tripping Characteristics: The Type C tripping curve provides instantaneous magnetic tripping between 5 and 10 times the rated current, making it suitable for circuits with moderate inrush currents. The thermal element responds to sustained overloads, while the magnetic element provides rapid protection against short circuits.

Breaking Capacity: With a rated breaking capacity of 6kA at 415V AC, the TBC-410M is designed to safely interrupt fault currents in typical residential and commercial installations. The breaking capacity is sufficient for most distribution board applications where prospective fault currents are within this range.

Construction: The circuit breaker features a thermoplastic housing with silver-plated contacts for reliable electrical performance. The toggle mechanism provides clear ON/OFF indication and manual trip functionality. Internal arc chutes safely extinguish arcs during interruption.

Durability: Rated for 20,000 mechanical operations and 4,000 electrical operations at rated current, the TBC-410M is built for long-term reliability in professional installations. The robust mechanism maintains consistent performance throughout its operational life.

Environmental Performance: The wide operating temperature range of -35°C to +70°C ensures reliable operation in diverse climatic conditions, from cold storage facilities to warm industrial environments. The IP20 rating provides protection against solid objects larger than 12.5mm.

Residential distribution boards and consumer units for whole-house protection
Commercial building electrical panels and sub-distribution boards
Light industrial installations including workshops and manufacturing facilities
Three-phase motor protection circuits with moderate starting currents
General low-voltage protection circuits in office buildings
Retail and hospitality electrical distribution systems
Educational facilities and institutional buildings
Agricultural installations and farm buildings
Renovation and retrofit projects requiring reliable circuit protection
Backup power distribution systems and generator circuits

Parameter	Specification
Electrical Characteristics
Rated Voltage (Un)	415 V AC
Rated Frequency	50 / 60 Hz
Rated Impulse Voltage	4 kV
Network Type	AC
Rated Current (In)	10 A
Number of Poles	4P
Tripping Technology	Thermal-Magnetic
Tripping Curve	Type C
Tripping Time	t < 0.1 s
Breaking Capacity	6 kA
Mechanical Characteristics
Control Type	Toggle
Mounting	DIN Rail (35 mm)
Mechanical Durability	20,000 cycles
Electrical Durability	4,000 cycles
Dimensions
Height	78 mm
Width	72 mm
Depth	66 mm
Environmental Conditions
Operating Temperature	-35 °C to +70 °C
Relative Humidity	0 – 95 %
Degree of Protection	IP20
Standards & Compliance
Standard	IEC 60898-1
Certifications	CE, CB, TÜV
